TC5082P Oscillator and Reference Divider
| Pin | Name | Description |
|---|---|---|
| 1 | Oscillator Frequency Output | |
| 2 | X-tal Oscillator | |
| 3 | X-tal Oscillator | |
| 4 | ||
| 5 | Vcc | |
| 6 | ||
| 7 | Oscillator Frequency Output Divided by 1024 | |
| 8 | Oscillator Frequency Output Divided by 256 | |
| 9 | GND |
