TC5080P Programmable Divider
| Pin | Name | Description |
|---|---|---|
| 1 | Prog. Input 1 | |
| 2 | Prog. Input 2 | |
| 3 | Prog. Input 3 | |
| 4 | Prog. Input 4 | |
| 5 | Prog. Input 5 | |
| 6 | Prog. Input 6 | |
| 7 | Prog. Input 7 | |
| 8 | Prog. Input 8 | |
| 9 | GND | |
| 10 | PD | Programmable Divider Output to PLL |
| 11 | ||
| 12 | ||
| 13 | ||
| 14 | ||
| 15 | Frequency Input from VCO | |
| 16 | Vcc | Positive Suppy Voltage |
